- 24 -

Installation Test Requirements

The chart below indicates which tests are available for an Electronic Control Unit (ECU). If there is a YES

next to the test name, that speciﬁc test is required in order to complete the Installation Test. If there is a

“NO” shown for a test, that test is not required in order to complete the Installation Test. If there is an “N/A”

shown for a test, this indicates that the ECU does not support that specific test. As a result, the test will not

appear in the Installation Test list. For the wheel speed sensors, at least one of the two sensor tests is

required – indicated by the word “ONE” in the chart. Bendix recommends that the full sensor test be run,

although the simple sensor test is an acceptable option.

All the tests in the table below refer to Bendix

EC-60

Controllers.

ECU Feature(s)

Advanced

(ADV)

Advanced(ADV),

Multi-Channel (MC)

Multi-Voltage

(MV)

Multi-Voltage (MV),

Multi-Channel (MC)

Installation Test

ECU Information YES YES YES YES

Installation Angle YES YES N/A N/A

Axle Load YES YES NO NO

S-C Sensor or Simple ONE ONE ONE ONE

S-D Sensor or Simple ONE ONE ONE ONE

S-E Sensor or Simple N/A ONE N/A ONE

S-F Sensor or Simple N/A ONE N/A ONE

P21 Modulator YES YES YES YES

P22 Modulator N/A YES N/A YES

Pressure Sensor YES YES YES YES

Battery Voltage NO NO NO NO

ABS Indicator Lamp NO NO NO NO

AUX I/O NO NO NO NO

Scratch Pad YES YES YES YES
