8
SNAP BUSHING
SECURELY
INTO PLACE
2ND
SECURE STUD
WITH
FLANGE HEAD NUT
TILT STUD
AS SHOWN
TO INSTALL
1ST
ROTATE
TO
INTERNAL
STOP
AX05
STEP ONE
STEP TWO
STEP THREE
ALIGN ARROW
WITH SLOT
Anchor Stud Installation
Figure 13 Anchor Stud Installation
