Compressor Installation and Application Review

Section IV Air System Components (cont’d)

Compressor Air Induction System - Naturally Aspirated Compressor Applications Only

(Cont’d)

Line size _____________________________________

Line length ___________________________________

Expected/Measured Worst-Case Inlet Air Temperature: _______________

Was measured restriction less than 25 in H

O? YES NO

Is the inlet air temperature greater than 170°F? YES

Recommended Test Procedure:

Install a temperature probe in the air compressor inlet hose or fitting as close to the

compressor as possible. Operate the vehicle such that the engine is at operating

temperature and the compressor is loaded/pumping. Record the compressor air inlet

temperature and note the ambient temperature. To obtain the maximum air inlet

temperature, add the difference between the recorded inlet temperature and the noted

ambient temperature to the maximum expected ambient temperature.

Was the restriction measured per the recommended procedure? YES

If no, describe the procedure used: ___________________________________________

_______________________________________________________________________
