Bendix

BA-921

Compressor Installation and Application Review

Section IV Air System Components (cont’d)

Discharge line

First component after compressor (filters, separators, traps, dryers)

What: _________________________________________

Line size to: ____________________________________

Distance to: ____________________________________

Second component after compressor (filters, separators, traps, dryers)

What: _________________________________________

Line size to: ____________________________________

Distance to: ____________________________________

Third component after compressor (filters, separators, traps, dryers)

What: _________________________________________

Line size to: ____________________________________

Distance to: ____________________________________

Is the discharge piping routed in a downhill manner to the air dryer?

YES

Measured compressor discharge pressure

(measured at the compressor) ______________________

Recommended Test Procedure:

Install a pressure gauge at the discharge fitting of the compressor and record the

discharge pressure at the time of governor cut-out with engine at rated speed.

Was measured discharge pressure greater than 170 psi? YES

Page 11 of 18
