Your trailer has two wheel speed

sensors and two ABS modulators

that are plumbed for axle control.

The MC-30

™

controller you have

installed is currently conﬁ gured for

4S/2M axle control.

Provide power to the MC-30

™

controller

and verify the current conﬁ guration

using the LEDs or blink codes.

4S/2M Axle

Hold magnet in place for 20

seconds.

The LEDs will begin to roll as the

installed sensors and modulators are

detected.

Remove the magnet.

2S/2M Axle

Stop! You do not need to perform an

ABS control toggle in this case.

Verify the new conﬁ guration using

the LEDs or blink codes.

4S/2M Axle to 2S/2M Axle

CHART 7 - EXAMPLES OF SELF-CONFIGURATION AND ABS CONTROL TOGGLE (2 of 2)

Your trailer has two wheel speed

sensors and two ABS modulators

that are plumbed for side control.

The MC-30

™

controller you have

installed is currently conﬁ gured for

4S/2M side control.

Provide power to the MC-30

™

controller

and verify the current configuration

using the LEDs or blink codes.

4S/2M Side

Hold magnet in place for 20

seconds.

The LEDs will begin to roll as the

installed sensors and modulators are

detected.

Remove the magnet.

2S/1M Dolly-Axle

Stop! You do not need to perform an

ABS control toggle in this case.

Verify the new conﬁ guration using

the LEDs or blink codes.

4S/2M Side to

2S/1M Dolly-Axle
