As ﬂ eets continue to experience the advantages of Bendix

Air Disc Brakes and the number of vehicles with this

technology gr

ows, there is an increasing need to have information on the brake chambers that are used on this

equipment.

To make it easier for you to service your vehicle(s), below is some key information on service part numbers, maintenance

kits, and a cross reference guide.

A. Universal Replacement Chamber Guide

There are many OEM air disc brake chamber part numbers utilized by truck ﬂ eets. However, as with S-Cam chambers, the

recommended service replacement part is provided in a “universal” conﬁ guration by Type and Size of the chamber itself.

This greatly simpliﬁ es stocking requirements. Here is the Bendix Air Disc Brake Chamber universal part number quick

reference guide.

Bendix

EverSure

Air Disc Brake Spring Brake Chamber

Type* Stroke

Spring Brake

Universal

Replacement

Part No.

Diaphragm

Kit

Clamp

Ring

Kit

Dust

Plug

Bellows

Kit

T16/24

2.25”

(57mm)

K042457 K052484

K090235

K034202 K090594

T18/24 K043329 K052484

T20/24

2.50”

(63mm)

K041960 K052486 K090236

T22/24 K043148 K052487

K090237

T24/24 K043270 K052488

3/8”-18

NPTF Ports

* The chamber type is noted as TXX/5.6kN on the chamber bar code label. Note that 5.6kN refers to the force of the power spring.

Air Disc Brake spring brake chamber for trailers part number K026451 has been replaced by part number K043329.

Type Stroke

Spring Brake

Universal

Replacement

Part No.

Diaphragm

Kit

Clamp

Ring

Kit

Bellows

Kit

T14/24

2.25”

(57mm)

K026735 — —

K090594

T16/24 K026731 K052484

K090235

T18/16 K027557 K052485

T18/24

2.50”

(63mm)

K025670 K052486

K090236

T20/24 K025669 K052486

T22/24 K026737 K052488

K090237

T24/24 K026734 K052488

NG-3

™

Piston Style Spring Brake Chamber

3/8”-18

NPTF Ports

Bendix

Air Disc Brake Chamber Service Information

Air Disc Brake Service Chambers

Type Stroke

Service New

Universal

Replacement

Pc. No.

Diaphragm

Kit

Clamp

Ring

Kit

Bellows

Kit

T12

2.25”

(57mm)

K028227

— —

K090594

T14 K028039

T16 K028226 K052484 K090235

T18

2.50”

(63mm)

K028022 K052486

K090236

T20 K028225 K052486

T22 K028238 K052487

K090237

T24 K028252 K052488

3/8”-18

NPTF Ports

Universal replacements may require re-clocking of the clamp band. See Bendix Service Data Sheet SD-02-4525 for instructions on re-clocking.

Size and Ref. Part Number

are stamped here

1 2 3 4 5 6 7 8

Summary of Contents

Page 1

1As ﬂ eets continue to experience the advantages of Bendix® Air Disc Brakes and the number of vehicles with this technology grows, there is an increas

Page 2 - Ring Kit, Bellows Kit):

2Item No. DescriptionKit ContentsDiaphragm KitClamp Ring KitBellows Kit1 Diaphragm 1 — —2 Bellow 1 — 13 Spring 1 — —4 Lock Nut 2 — 25 Screw 1 1 —6 Hex

Page 3

3C. Bendix Air Disc Brake Chamber – OEM to Universal AM Replacement Cross-Reference InformationBendix Air Disc Brake Service ChambersOEMPart No. Siz

Page 4

4Bendix Air Disc Brake Service Chambers, continuedOEMPart No. Size StrokeUniversal AMReplacement Kit5016678T222.50”(64mm)K0282385016679501668050166815

Page 5

5OEMPart No. Size StrokeUniversal Replacement AM Part No. (Piston Style) Ref PN 5018436T18/24 2.50”(64mm)K025670 K011236501843750184505018451501973450

Page 6 - Bendix EverSure

6Bendix EverSure® Double Diaphragm ADB Spring BrakesOEMPart No. Size StrokeUniversal ReplacementAM PN – EverSure® ADBK042441T16/242.25”(57mm)K042457K0

Page 7

7OEMPart No. Size StrokeUniversal ReplacementAM PN – EverSure® ADBK057414T20/242.50”(64mm)K041960K059877K059878K065543K043136T22/242.50”(64mm)K043148K

Page 8 - Visit www.brake-school.com
